Cone Tapered Flagpoles

Cone Tapered Flagpoles
Material

30' Cone Tapered Flagpoles, Kelowna, BC
30' Cone Tapered Flagpoles
Kelowna, BC







Flag Size
Length Cable
# of Beads
# of Grommets

Grommets
Spacing

7.5"x15'
96
1
1
45"
9'x18'
113
2
2
36"
10'x20'
122
2
2
40"
12'x24'
148.75
2
2
48"
15'x30'
193
3
3
45"
15'x30'
241.75
3
4
48"



  6063 T-6 Aluminum
Finish:


Brush Finish
Optional:
Clear Anodize
Bronze Anodize
Black Anodize
Powder Coated

Halyard:


External Halyard Rope & Cleat
Optional:
Internal Halyard (Lock & Door)*
Internal Halyard (Gearless winch)

Ball:
  Stationary Ball
Optional:
Rotating Trucking Ball
Mount:
  Stationary Base
Embedded In-Ground
Optional:
Tilt Base


Cone Tapered Flagpoles Specs Additional Options
Item #
Size
Price
Ball Dia.
Min Flag
Max Flag
Internal Halyard
Revolving Ball
Clear Anodize
Tilt Base
761000
25'x4"x2"x.125" (Not Recommended)
$1854
6"
3'x 6'
3'x 6'
$300
$205
$241
$122
761100
25'x5"x3"x.125"
$2143
6"
3'x 6'
45"x 90"
$350
$205
$328
$124
761600
30'x5"x3"x.125"
$2402
6"
3'x 6'
4.5'x 9'
$350
$205
$395
$124
761650
30'x5"x3"x.156"
$2744
6"
3'x 6'
5'x 10'
$350
$205
$355
$124
762200
35'x5"x3"x.156"
$3165
6"
45"x 90"
5'x 10'
$380
$205
$418
$124
762300
35'x5"x3"x.156" 2-pc
$3328
6"
45"x 90"
5'x 10'
$380
$205
$418
$161
762500
35'x 6"x3.5"x.188"
$4118
6"
45"x 90"
6'x 12'
$330
$394
$515
$245
762600
35'x 6"x3.5"x.188" 2-pc
$4397
6"
45"x 90"
6'x 12'
$380
$394
$515
$245
763100
40'x7"x3.5"x.156" 1-pc
$4324
6"
45"x 90"
6'x 12'
$395
$394
$595
$254
763150
40'x7"x3.5"x.156" 2-pc
$4728
6"
45"x 90"
6'x 12'
$395
$394
$595
$254
763200
40'x7"x3.5"x.188" 2-pc
$4914
6"
45"x 90"
7.5'x 15'
$395
$394
$595
$254
763500
50'x8"x3.5"x.188" 2-pc
$6250
8"
4.5'x 9'
9'x 18'
$420
$394
$874
n/a
763800
60'-66'x10"x4"x.188" 3-pc
$9296
8"
5'x 10'
10'x 20'
$450
$699
$1450
n/a
764100
70'-77'x10"x4"x.312" 3-pc
$15893
12"
6'x 12 '
12'x 24'
$480
$699
$1689
n/a
764300
80'-88'x12"x4"x.375" 3-pc
$27421
12"
9'x 18'
20'x 40'
$500
$699
$2274
n/a

Facts and Additional Information
  • 80% of all flagpoles are sold with an internal halyard, rotating ball, tilt base and anodized finish
  • Factors that increase strength are the pole di
  • ameter and of secondary importance is the wall thickness
  • The most common ground mount flagpole sizes are 25' - 35'
  • One should always match the flag to the flagpole. As a guideline, the length of the flag should be at least 1/4 of the height of the flagpole
  • Anodizing aluminum creates an extremely strong coating over the aluminum, making it stronger & more scratch resistance
  • Satin brush finish is sanded aluminum. Untreated aluminum looks great at first, but after a year will dull and after 7 years will stain. We recommend anodizing all flagpoles

  • The rotating ball is used with the internal halyard cable & for changing wind directions
  • The internal halyard door is 3-3/8"x 5-1/8" on most poles
  • The tilt base allows one person to erect the flagpole, saving money on installation & maintenance. The shoe is welded to the flagpole.
  • All parts are non-corrosive.
  • The above flags sizes do not constitute a warranty that all flags may be safely flow in all windspeeds.
  • We offer a two year warranty on all flagpole with an optional lifetime warranty (click here for warranty info)
Important information please read!
 Warning! - Wet or damp cardboard wrapping will stain flagpole. Be sure to store your flagpole unwrapped.
